Classic Pallet Inverter Floor Level

The “Classic Pallet Inverter Floor Level” is one of the classic pallet inverter by Toppy, launched in 1988 and still one of our best sellers today. It’s designed for exchanging pallets for products that can be momentarily turned upside down.

35 pallets per hour.

Able to load and unload at ground level;

Handling loads up to 3.300 lbs (1.500 Kg)

pallet flipper ground level

pallet flipper with boxes

Pallet Flipper Inverter floor level

Pallet Flipper floor level

Pallet flipper with forklift

pallet flipper in inox

Operational Description of Inverter Floor Level

This pallet flipper operates by rotating the entire pallet load 180°, positioning the pallets on top for convenient exchange by the operator. This complete load rotation significantly saves time and labor in warehouse operations.

Here’s how it works:

  1. The pallet carrying the load is initially placed on the lower platform – manually (using a forklift) or automatically (via conveyor belts).

  2. Two additional platforms secure the product, preventing any movement or spillage during the process.

  3. There is a 180° rotation of the load, allowing the operator to exchange the pallets once they are at the top of the load.

  4. After pallet exchange, there is back a 180° rotation of the load. The load is now to its original position with a new pallet.

  5. Release at ground level for loading or stacking, where a forklift operator can take over.

This solution falls within the broader category of pallet inverters, which are tools for managing and manipulating pallets across various industrial and commercial applications.
